So I’m fairly up in my geometry mtb wise and happy with both my bikes.
On the road bike front I’ve always been pretty happy with my Cannondale caad12 disc (54cm size) - although I’ve run it as it came new with all the spacers under the stem - but with the angle of the stem down rather than up. I’ve also always been a bit annoyed it doesn’t have mounts for proper mudguards.
Up sides are it’s pretty light (1150g frame I think), handles nice and snappy and fun cornering for a road bike.
Mines got Ultegra di2 and Hunt 4 seasons road wheels.
With a recent back spasm it’s a bit on the low side at the front and have flipped the stem to point upwards which is better - but it looks daft.
So I’d like to pick up a new frame that does the following:
Higher front end
Still light - looking for frame only 1200g or less
Mudguard mounts
Discs
Bolt through axles
Not devastatingly expensive (£1500 max for the frameset if I can use cycle 2 work vouchers)
About all I’ve been able to find that might fit the bill is the Ribble Endurance SL. Frameset only is £1400 - pretty much any other frameset I get will mean new cranks (as I have stupid bb30a) and a new front caliper as mine is post mount front / flat mount rear.
The headtube is 11mm taller and weight should be similar. It has mudguard mounts and looks pretty nice.
I went into Ribble today to have a look at one and was hoping to get a sit on it. But apparently they don’t do that - you have to sit on a seperate jig (even though they had a medium of the bike I want literally in the shop) and someone was about to start a fitting on it. I had my 5 year old with me so no way she was going to wait for it to be free and whilst I got on. Very frustrating.
The guy in the shop said I might actually be better with their R872 as it’s more relaxed geometry again than the endurance sl. It doesn’t look quite as nice and doesn’t come frameset only - but could buy the basic tiagra one for £1500 and flog the bits I don’t need - might fund the cranks and a chunk towards some carbon wheels.
The below link should go to a geometry geek comparison of the caad / R872 / endurance sl. I stuck in the snallnof each but I think it’s medium I’d want.
Any thoughts on the options would be much appreciated. I assume stack is made up of wheelsize / fork length / head tube length?
I didn't think either Ribble was all that relaxed to be honest, then again I've got poor flexibility etc. Have you considered the Canyon Endurace or the Giant Defy - they appear to have the sportive geometry pretty much nailed. The Boardman SLR is supposed to be good too.
I saw the Boardman SLR 8.9 but haven’t seen it for sale frameset only. With a quick look the 54cm equivalent size has a lower stack and shorter headtube than my caad12 by the look of it. So that’s probably out.
I thought the endurance was quite racey from a review I read a few years ago.
Haven’t thought about the Defy - will have a look.
I spent a lot of time looking for a road bike with a good stack height, I'm tall and have a dodgy wrist so wanted a fairly upright position. Canyon tend to be more generous with stack height than most and I think Trek are as well (though with reduced reach).
I ended up getting a gravel bike that works well with road tyres as they tend to have a greater stack height. I also raised the stem as much as possible, got Ritchey Ergomax bars and extra thick bar tape. Obviously switching the stem is a bad look so I'm also looking at either a lower drop stem or perhaps a zero rise one.
Stack is the height of the top of the centre of the top tube drawn from an imaginary horizontal line through the centre of the BB... It basically dictates where your handlebars will be (for a given amount of stem spacers) in relation to your feet, height wise...
Reach is similar, but dictates where your handlebars will be (for a given stem length), in relation to your feet...
If you're struggling with your CAAD12, a bike with 12mm greater stack heigh is not going to cut it I'm afraid!!!
If you’re struggling with your CAAD12, a bike with 12mm greater stack heigh is not going to cut it I’m afraid!!!
It may do but you are probably right. If flipping stem has made it okay then just work out how many mm that has risen the bars and shortened reach. This is handy for working it out http://yojimg.net/bike/web_tools/stem.php
A quick go based on 100mm 10 degree stem puts the bars 33mm higher and 10mm less reach when flipped which is a fair bit of difference
If flipping stem has made it okay then just
ride the bike and quit worrying
ride the bike and quit worrying
As well as the height of the front the mudguard thing is a annoying me a bit the last few years. Used clip on ones which are ok - but the rear has moved around and taken paint / possibly a little bit of metal out of the seat stays 😬
Plus I’ve had it since 2018 and I fancy a new shiny frame too!
I’m considering some group road rides with the local triathlon club too - and if the road is wet then proper mudguards are required to not throw muddy water in the face of the person following.
I’ll have a look at some lighter duty gravel bikes that don’t have room for massive great tyres. When I previously looked they were all quite a bit heavier than the caad though and I don’t want to lose the nice whippy feeling it has too much.
I was looking for similar to replace my old bike. I eventually bought a Giant Revolt gravel bike (current gen). I run 32mm road tyres, and am fitting my full length mud guards tonight. I've done big days out in the mountains, and it works perfectly fine as a road bike.
The Ribble CGR SL might work - stack is higher than the road versions and it’s still light. Bit more expensive though.
Wonder if the large Planet X space chicken might work if I can find a secondhand frame only - need to look into the geometry a bit more. If I could get one cheap I could go custom paint with my local frame painter which could be cool. Nice candy metallic purple perhaps
How about riser drop bars on the CAAD? For +10-15mm height they can look ok if you don't want a flip-up stem. Kind of odd but ok. TBH if 10-15mm makes the difference could you work on core strength and flexibility and keep the bike - the CAAD10-12 frames are classics.
I’m considering some group road rides with the local triathlon club too – and if the road is wet then
go mountain biking? Shudders at the thought of bunch riding with triathletes in the wet
: )
...I’m considering some group road rides with the local triathlon club too – and if the road is wet
If the road is wet you won't need to worry about anyone behind you, they'll all have fallen off on the first bend.
Edit: dammit, beaten by @jameso ...!
Haha - I mostly mountain bike - got a Transition Sentinel and a Marino hardtail.
But sometimes the road is good for a fitness boost / to not get filthy muddy.
If the road is wet you won’t need to worry about anyone behind you, they’ll all have fallen off on the first bend.
Edit: dammit, beaten by @jameso …!
Lol - they did cancel last Sundays ride as it was “too wet” 🤷♂️
Function over form?
Grab an adjustable stem such as https://www.chainreactioncycles.com/deda-elementi-adj-adjustable-stem/rp-prod158477 that I have on my "58cm" Cube Attain GTC Pro Disc '16 for the opposite reason to you OP, to lower the front end now my lower back is far better than it was nearly six years ago.
Cube Attains have massive amounts of stack, my "58cm" (no tube is that length) has 388mm reach and 610mm stack, iirc the "56cm" (that @molgrips has iirc) is 385/591mm respectively.
I'm 5'10" (178cm) with stumpy legs, running ~89.5cm pedal top to saddle top.
No idea if this is the cheapest place, but here's a ninja version https://www.paulscycles.co.uk/bikes/road-bikes/cube-attain-sl-road-bike-2022-greyblack__8801 for £1487
There will be no adjustable stems on my bikes!
But the Cube point you raised is interesting - they do seem to have a big stack / tall headtube. Will have a look round at those - thanks 😊
Did anyone else wince at "only £1,400" for a Ribble frame? I paid about £300 for my old carbon Ribble sportive frame and fork.
Nothing wrong with riding a flipped stem OP, but I acknowledge fixed guards are a wonderful thing for riding in the wet.
There are some deals about on the new Synapse complete bikes already.
If you're interested in a PX gravel bike, their full builds are good value and you could keep two sets of wheels to swap between road and gravel.
But is the need for relaxed geometry a permanent thing? Have you ridden an endurance bike on the road before? I know they're very popular, but I had a nice Defy for a few years and I always found it a bit unengaging compared to my more sporty road bikes.
If you otherwise like the CAAD12, maybe have a look at a Synapse?
Not sure if they do a frame only but the 105 version is in your budget, downsides it's 'old' 11s 105 and cable disks.
FWIW Cannondale have always come up quite large for their size, i.e. slightly longer reach than most brands. So you may also be stretching to the bars slightly if you're a 54cm from other brands. Road bike geometry is a funny thing, half a degree here or there that you wouldn't notice on an MTB suddenly becomes a deal breaker when you're sat still on it for 4 hours.
Proper full length guards are brilliant, and completely underrated by anyone who makes do with the various clip on versions.
But the Cube point you raised is interesting – they do seem to have a big stack / tall headtube. Will have a look round at those – thanks 😊
Specialized have changed the geometry on them now but if you can find a Roubaix from a year or two ago, they were renowned for tall headtube / high stack geo.
The current ones are much closer in geo to the Tarmac, it has gone back to being a "rougher roads" race bike.
I use my old Diverge as a winter roadbike, does a good job.
Plus I’ve had it since 2018 and I fancy a new shiny frame too!
Fair enough I suppose.
I’m considering some group road rides with the local triathlon club too – and if the road is wet then proper mudguards are required
Going out with a group that doesn't enforce this rule is a mistake you only make once 🤣
So the Cube Attain doesn’t appear to have mudguard mounting points - neither does the Specialized Roubaix. 2 options out there.
I tried to find a carbon synapse frame only but failed so far (new ones). I think pre-Covid stuff like that was available but Cannondale seem to have only had full bikes or really top end hi-mod System 6 / Super 6 frames available since.
Mudguards make sense in a group otherwise you end up with a face full of muddy water for 3 hours. Mtb you aren’t riding close together so other than a front mudguard over the wheel to keep mud out the eyes I don’t bother.
My comment on the price of the Ribble wasn’t “it’s only £1400”, but “frameset only is £1400” - I.e not as a full bike.
Mudguards make sense in a group otherwise you end up with a face full of muddy water for 3 hours
They do but overly officious rules do my head in. It's fairly easy to avoid following the wheel of someone with no guards and clip ons do a reasonable enough job if you only have one bike and it doesn't have mounts. Even with most fitted guards they are not long enough to stop spray into a following riders face, most need an extra flap or need to be as long as the ones on my bike very few are.
But is the need for relaxed geometry a permanent thing? Have you ridden an endurance bike on the road before? I know they’re very popular, but I had a nice Defy for a few years and I always found it a bit unengaging compared to my more sporty road bikes.
I’ve not ridden an endurance bike before but I’ve had back issues on and off since 2011 when I bulged some discs in my lower back. This recent issue is a back spasm according to the physio (haven’t been for a recent MRI) and I’m managing it with stretching and strengthening exercises which is helping - but at this moment in time I don’t see it going back to how it was before. Work bought me a fancy adjustable office chair and sit/stand desk which is also helping manage the back ache / pain.
I appreciate I’m going to lose some urgency in the handling - which is why I’m still trying to find something on the lighter end of things and haven’t really looked at gravel bikes. I’m not going to be going crit racing but equally I don’t want some heavy / dead feeling thing.
Cube Attains do have guard points for their own guards, I have a set! 😆
5sec google
Limits rear tyre to 29mm max, without no issues with 32mm GP5000. I run narrower front tyres, currently 25mm.
My comment on the price of the Ribble wasn’t “it’s only £1400”, but “frameset only is £1400” – I.e not as a full bike.
Makes more sense, ta.
Please don't pay £1.4k for a Ribble frame, you'll make them think it's OK to ask that much.
* no issues with 32mm GP5000 without guard!
I didn’t find those Cube mudguards / they weren’t mentioned in any of the reviews I’ve found - thanks. Back on the list!
On the Ribble front I’d be inclined to do it via cycle to work vouchers so I think a £1200 voucher over 12 months is £66 a month net…so it wouldn’t cost me a massive amount
It’s fairly easy to avoid following the wheel of someone with no guards
It's only easy if you ride as an undisciplined rabble. If you ride in a tight group with rotation then it's impossible. I've ridden with clubs who have taken both of these approaches - the undisciplined rabble imposed a considerably higher load on the NHS. This afternoon I'll be fitting my proper mudguards to the Gradient to put it into winter road bike mode.
Yeah I don’t want to get mashed up through someone being a dick on a road ride. The tri club fast group ride is fairly sensible with people warning of pot holes etc in good time. No-one seems to be intent on pushing the pace on and deliberately dropping anyone etc
I've just built a bike based on the Carbonda 696 frame (Same as On-one Freeranger, Tifosi Carvazzo, Bombtrack EXT-C, Dolan GCX). It has a 25-30mm higher stack than my road bike frames (Giant TCR, PX Pro Carbon) but still handles surpisingly nicely on the road.
Can obviously take full length guards etc. I'll probably do some club rides on it in the depths of winter.
I priced it up directly from China, and it was <£700 delivered. Current On-one Freerangers are £899 with an additional 20% off, so similar.
If you look on weightweenies, hundreds of people have built gravel/winter road bikes with this frame.
@benman - have you had any road bikes to compare how the freeranger rides?
Weight wise it doesn’t look too bad at 1350g for the frame - 200g more than my caad 12 probably. But I could sell my caad12 frameset and wheels and get some lighter carbon ones to offset that a bit.
Think it has a threaded bb so could sell my Cannondale Si crankset and get something from Shimano - or something with a power meter if I’m feeling flash.
Will have a dig around in weight weenies to find out a bit more about it.
So the Cube Attain doesn’t appear to have mudguard mounting points
Yep they do, this is the reason I bought one. They make specific full mudguards for them which have various cut-outs and mounts to fit. They aren't perfect as guards but they do fit perfectly, perfect lines and zero rattles. Very glad I have these without needing to bodge anything.
Don't over-tighten the bolts holding them on - it squidges the rubber pads out of place and you might lose them.
If you didn't have access to a genuine Cube set I think you'd be able to bodge a set using the threaded holes provided. I think other bikes might use the same method - Boardman?
@joebristol I've had loads of road bikes. I do 5000+ miles a year on the road.
I usually favour more racey geometry, but I've built the Carbonda frame (mines actually a Tifosi Carvazzo) as a commuter, tourer and to race the Dirty Reiver on next year.
I've been pleasantly surprised how nicely it rides on the road. The reach is about 5mm shorter than my road bikes, and stack is 25-30mm higher. I've got the stem slammed 🙂 It still handles quite nicely (my last gravel bike felt really unweildly on the road) and zips along. Averaged 18.5mph on one day of our cycle tour last weekend.
[url= https://i.ibb.co/HBRvRS7/IMG-20221022-094816.jp g" target="_blank">https://i.ibb.co/HBRvRS7/IMG-20221022-094816.jp g"/> [/img][/url]
There are some gopping on one colour schemes - I don’t know who designs them! Your Tifosi looks nice.
I have a mate who has a freeranger actually - forgot about that. His is built up for gravel but will see if I can go and have a look at it. £900 currently from Planet X which is a chunk cheaper than the Ribble.
On-one currently have 20% off if you are quick. And they do a solid black one now (the other colours are gopping)
Something worth noting though, is that the max chainset you can run is 50/34 on these frames.
If you ride in a tight group with rotation then it’s impossible
True but my winter rides are not chain gangs and I have no desire to pretend to be a racer especially if it's wet. Winter group rides are for chatting and eating cake not through and off smash fest's, if that means some riders only have clip on guards or shock horror no guards at all so be it, it's hardly the end of the world imo.
If you fancy a new bike/frame that's fair, but if you want to make what you have work...
Raceblade Pro XL mudguards are great and if you fit them as per instructions they won't mark your frame. They are also easy to take on and off once set up, which is why I use them rather than bolt on mudguards.
Riser handlebars can really help. I recently got a set of Specialized Hover Expert on eBay and they transform the way the bike feels without (I think) looking too bad. This possibly combined with some stem length adjustment might sort it out for you.
If you do get a new endurance frame, in classic STW recommend what you own mode - look at the Giant Defy range.
Winter group rides are for chatting and eating cake not through and off smash fest’
I'm not talking about a through and off bash. I'm talking about riding 2 by 2 in a group with regular rotation so that no one spends too long in the wind and you get to chat to different people. Very sociable. But it does mean that you are riding reasonably close behind people so mudguards and preferably mudflaps are a must.
Medium Defy. Or any 56cm 73 degree parallel steel or titanium frame with eyelets for mudguards would be my choice. The Cannodales come up quite large for a 54 due to the steeper seat tube angle. I'm guessing you're about 5'9"-5'-11". I rode a 54 CAAD8 and Medium Defy, but am normally a 56 for 73 degree parallel bikes (like my Paddy Wagon).
I'd get one of these Ti Audax from Spa Cycles in a 56.
https://www.spacycles.co.uk/m11b17s143p2371/SPA-CYCLES-Titanium-Audax-Frameset
EDIT - or an Elan since you wanted discs.
I’ve got Raceblades already - I think they’re the stealth xl - I hadn’t realised they’d worn through the frame protection tape I had underneath them - it was only when I took them off for the summer I noticed. Little bit angry about that!
50/34 wouldn’t be a problem for me - that’s what I’m running now. I found 52/36 hard work on the biggest / steepest hills. I also run an 11-32 Ultegra cassette - horror of horrors 🫣
That spa cycles frame isn’t floating my boat on looks. Call me picky. Plus it’s externally routed and I’ve got the di2 with full wires and that might look a bit odd external.
It almost certainly won’t be near 1150g frameset only either in steel.
You’re right on my height - I’m 5’9 - longer of leg / shorter of arm. My full suss mtb is 451mm reach and my hardtail is 445mm. I’m never really sure how you work out a sensible reach figure for road - I guess it’s less relevant than mtb as you only really stand when climbing. Etc is presumably more relevant?
Defy is something on my list now - along with the Cube attain, Ribble R872 and maybe a Free Ranger / Carbonda 696. Carbon Synapse if I can find a frame only.
Torn between trying to find something cheap secondhand or do a C2W scheme and get something new.
My carbon Defy doesn't have mudguard mounts and it's a while since they made an aluminium one.
Hmmmn, it’s a minefield.
At the moment the On One Freeranger or Ribble R872 are looking the most likely. Have to buy the R872 as a full bike and then flog all the bits I don’t need.
I can’t find the frame only weight for the R872 but looking at the full build weights it can’t be biblically heavy or anything.
If you're in Bristol you're welcome to come and see my Cube, it's 56cm. I can't fault it.
Defy is something on my list now
I have a Defy Advanced SL, but it doesn't have mudguard mounts, my other alloy one does - no internal DI2 though. Given your long legs, 54 sounds a better fit, but shorter HT. If 73 degrees parallel, sizing up might be better for your back. I run a steel trike with external DI2, but no FD so not so bad - in fact I don't really notice the downtube cable, battery is behind seat tube. If the headtube is long enough, get the Ribble, at least they have a long history of winter road bikes (the famous blue alloy frame of clubman choice in bygone years).
BTW for you budget, I was only suggesting Ti. Although their steel fixed wheel audax is a nice frame (down credit card, Down!)
Thanks @molgrips. So far I haven’t found a carbon attain frame only or full bike at a price I’d be happy spending. But will keep looking.
Just looked at the boardman slr 8.9 again and think the geometry is ok actually. It has a higher stack than what I’ve got in medium and a lot higher in large. Reckon the seatpost on the large is a similar height to my 54cm Cannondale but the ett is way longer.
Very tempted with the Free Ranger at the moment
If it were me and I had a nice s****y carbon Di2 bike and the sort of budget you seem to be mulling for this OP, I'd skip the Spa cycles Ti frame suggestion above and give serious consideration to this...
A ready to go winter bike, with guards already fitted and hydraulic braked 105, yes it's steel, but it'll be comfortable over winter with a nice long head tube and perhaps importantly will keep the Cannondale out of the muck so you won't find your clip on guards have started eating the frame next spring.
Plus when spring does roll round and you jump from that steel "boat anchor" to a nice carbon, leccy shifting race machine it'll feel like you're riding a chuffing rocket (for the first ten minutes at least).
If you're looking at upwards of £1k for a frame plus the faff of swapping parts you might as well just buy a whole 'winter bike'...
If you’re looking at upwards of £1k for a frame plus the faff of swapping parts you might as well just buy a whole ‘winter bike’…
That's what I'd do.
My carbon Defy doesn’t have mudguard mounts and it’s a while since they made an aluminium one.
The Aluminium Defy is just called a Contend now isn't it? Not sure if it has mounts for guards but I would expect so.
Here we go
https://www.giant-bicycles.com/gb/contend-sl-disc-1
How about doing some stretching and core work so you don't have to ride so upright. Or maybe a bike fit could be worth it instead of trying the perfect position by trial and error.
How about doing some stretching and core work so you don’t have to ride so upright. Or maybe a bike fit could be worth it instead of trying the perfect position by trial and error.
Meow!
But perhaps the issue isn't just core strength?
You've flipped the stem OP, but how long is it? Might the stock stem be too long?
Like you OP IP I'm an annoying height (5'10”) putting my between 'M' and 'L' or 54 and 56 on most manufacturers size charts. What I've found is that where I size up to a 56 running a shorter than stock stem (70-80mm seems to work for me) can make a substantial difference.
The only Cannondale I've ever ridden in anger was a synapse rental where I accepted the stock 54 and got along fine with it although the wheel base felt kind of short and the front wheel a bit close on some turns...
At the moment the On One Freeranger or Ribble R872 are looking the most likely. Have to buy the R872 as a full bike and then flog all the bits I don’t need.
I can’t find the frame only weight for the R872 but looking at the full build weights it can’t be biblically heavy or anything.
Wife has an R872 as a winter bike, 28mm GP5000s and proper full length mudguards. Perfectly decent frame - stock wheels were a bit cheap / heavy (Mavic Aksium disc)
I’m coming round to the idea of the on one freeranger I think.
Planet X have confirmed frame only is 1350g so it’s not wildly heavy.
It has plenty of room to run say 28c tyres with mudguards
Stack is quite high
I can bike to work voucher it - frame only is £899. So will cost me £46 a month net for 12 months according to the calculator - plus the lease final cost. Total just over £600.
Think I’d need to buy headset / bb / cranks / maybe a new rear brake hose / RX4 flat mount front caliper / bolt through end caps for my hunt wheels.
Not planning on having 2 road bikes - just the one. Caad 12 is aluminium and I love di2 - so I don’t want a winter road bike without it.
I’m coming round to the idea of the on one freeranger I think.
We both have them as gravel bikes! Nice bikes, probably a bit chunky for a dedicated road machine IMO - plus I have a dedicated winter and summer road bikes already....
I'd try a shorter stem first, but if a whole new bike is the preferred solution it sounds like 20mm less top tube and/or adjusting those contact point positions when you build it up would be of significant benefit...
I think I’m leaning towards a free ranger with all my existing components that fit - then get a bike fit before thinking about changing stem / handlebars.
It will probably be a very boring looking black one as the other 2 colours aren’t to my taste. The 2 tone poo colour is particularly minging.
I’m not going to be road racing per se - mostly commuting / turbo training / some local hills for fitness + some tri club rides.
I may do a triathlon but probably won’t even bother with clip on tri bars - it would just be surviving rather than competing.
didnthurt
Full Member
How about doing some stretching and core work so you don’t have to ride so upright. Or maybe a bike fit could be worth it instead of trying the perfect position by trial and error.Posted 38 minutes ago
REPLY | REPORT
cookeaa
Full Member
How about doing some stretching and core work so you don’t have to ride so upright. Or maybe a bike fit could be worth it instead of trying the perfect position by trial and error.
Meow!But perhaps the issue isn’t just core strength?
I don’t think I’m hugely lacking in core strength and aside from my lower back I’m pretty flexible.
I’m doing all the stretching and exercises from the physio so core strength is only going to get better.
Specially:
Glute bridges
Toe taps
Plank
Good mornings
Stiff leg deadlifts
Goblet squats
I've never really thought about road reach figures but I think my road bike is around 400mm, my mtb's are 510/528 and I'm 195cm tall. I don't know if that gives a reasonable % shorter that you would expect a road bike to be
It’s a bit of a mystery to me tbh on road bikes.
Thinking if I go free ranger then I’ll get an Ultegra 50/34 crankset and bb - which will match my Ultegra di2 stuff and should last ages. Bit heavier than my Cannondale si with spider rings but that isn’t fitting a base screw in bike.
Going to speak to Hunt and check the version of wheels I have can still be converted to bolt through / they stock end caps.
Need to check the RX4 flat mount rear caliper is the right one for the frame / rotor I have.
Someone has a Carbonda 696 thread running on here so will try to dig that out for a look.
@dc1988 At a guess, you have 110/120mm stem and then bars with ~75mm reach, so the road bike has ~590mm effective reach on the hoods. ~50mm stem on MTB would give you ~565mm effective reach to bar ends, depending on their sweep/width.
Just found the Dolan GXC looks to be almost the same Carbonda frame but with a nicer looking fork. Fired off a few questions to them about weight (they claim 1500 frame and fork and a t700/t800 mixture of carbon instead of just t809), whether theirs is a pressfit version etc.
They have nicer colours than Planet X!
A medium Dolan seems to have a shorter reach and 20mm higher stack than the caad12 54cm. I think that’s what I’m after.
This is the geo comparison of my current bike to the medium and large Dolan. Think the medium is the one. Same for the free ranger I believe.
If you like fast handling, I wouldn't be looking at a 71.5 degree head angle. Either 73 (traditionally parallel with same seat tube angle) or 72.5 with slightly steeper seat tube angle (gives a shorter TT) would be my choice. Geometry counts far more than weight. A light frame with slack geometry will always feel like it handles slowly. A steel racing geometry frame with an extra kilo (2x 500mL water bottles if you like), will handle like a carbon bike. Alloy frames, with larger diameter tubing, can be stiffer than carbon. Both can be stiffer than steel/titanium (there is little difference other than about one water bottle in weight). Your Cannondale has pretty traditional road geometry and you'd notice a slack head tube angle more than the weight.
I would second the bike fit suggestion. You haven't bought the frame/bike so you can completely start from scratch. Get on a jig and get the exact measurements that work for you (with assistance/advice from fitter) then armed with that go and look for a frame that can match. There may be other things that would help than just changing stack.
I have a Kinesis Racelight as a winter bike. Not sure what the stack is like on it, but I'm fairly upright on it and I've been able to get it to fit the same as my Trek Emonda. It has mudguard mounts, that work a treat at keeping me and others dry. Might be worth considering if you are open to another aluminium frame.
I think the equivalent race light frame has a lower stack than what I have now and shorter headtube. The Kinesis scandium frame looks interesting though - similar stack and ett / headtube length to the GXC. Also a little slacker headtube again.
I think I may have to compromise slightly on the quick handling to get the more relaxed position I want - whilst also staying in budget. Being comfortable if more important. I’m going to have a look into bikefitters around the area and see what’s what there.
Just to say: +1 on get a bike fit, mainly because it sounds like you have some specific needs and issues, and a decent fitter will offer advice and insight alongside geo numbers. They seem expensive - especially if they end up telling you what you basically know - but consider it an investment. Also, it doesn't take many stems/bars and eBay fees to add up to the cost of one. (I am getting one soon before I alter anything else).
I ride a more roadlike gravel bike - Revolt Advanced - as a road bike (as well as gravel), but am always wary of the answer to the question 'what road bike'? being 'a gravel bike'. Like, this thing has a 71⁰ head angle, which is very much not road geo, and I'm really beginning to get why road bikes are how they are. There might be more endurancey offerings that suit you better - though I appreciate the Carbonada set up 2x might be it, esp if you are looking for something now.
+1 for the bike fit. Really worthwhile.
Sounds like you've chosen a freeranger but I'll add my 2p as well that's what forums are for.
I have a cannondale supersix as my summer bike and a Focus Paralane (endurance) as my winter bike. The focus is my first choice as it is so comfortable with a considerably higher stack. The frame also has discrete mounts for mudguards deesjgned specifically for the bike which are silentin use. You can pick them up cheap on ebay as they don't seem as popular as the spesh etc endurance bikes.
@nt80085 - I’ll have a look at the Foxus as it’s not a brand I know well.
A mate has a Planet X hurricane that I might try and get a quick go on too.
But the Dolan GXC is top of my list right now - broadly the same as the freeranger but I can get it without the fork with bolts all down it and in a nice colour. Plus can roll in the cost of the other bits I need to one cycle to work voucher.
Found a bike fit person who is also a physio and specialises in sports rehab. Going to see if they have a proper jig thing or just fit on your own bike.
I use my old Diverge as a winter roadbike, does a good job
Snap...
[url= https://live.staticflickr.com/65535/52462556018_f5d10903bc_z.jp g" target="_blank">https://live.staticflickr.com/65535/52462556018_f5d10903bc_z.jp g"/> [/img][/url][url= https://flic.kr/p/2nVWj8U ]Specialized Diverge[/url] by [url= https://www.flickr.com/photos/brf/ ]Ben Freeman[/url], on Flickr
Any suggestions for a particularly stable frame?
A friend of mine is getting on and feels increasingly nervous on relatively twitchy road bikes and is looking for a more comfortable and stable ride. He is very tall,6'4", and is convinced this adds to his feelings of instability. I am not sure about that but he certainly needs a more reassuring bike.
I think from what I’ve found a properly sized endurance style bike with a decently high stack. The more gravel orientated bikes have a slacker head angle which will also contribute to a more stable feel.
What’s he riding now that’s twitchy?
A Giant TCR of some sort that he has had for years. I used to have one and didn't think it was particularly nervous but I was a lot younger then!
Wasn't there a back problem mentioned in the OP?
See a physio who also does bike fitting, you can probably get a recomendation off here.
Apologies if this takes the thread a little off topic, but I went for a road bike ride yesterday in heavy winds that got me thinking about road bike geometry. Just some context - long time mtb'er, a bit of a bike geek and like the OP I'd like to think I've got a decent handle on mtb geometry and the changes of the last 7 or 8 years etc. I know very little about road bikes. I have one for the turbo and some road rides purely for fitness to make my mtb riding more enjoyable. i.e. the fitter I am, more I can enjoy the descents and not finish rides buggered.
Anyway, road ride yesterday in heavy winds, and I had two or three very scary moments where a gust of wind caught me and nearly blew me off. Fair enough it was just the conditions and it was properly windy, but the bike was properly titchy and it was not pleasant. It just got me thinking though, why hasn't road bike geometry moved to longer, more stable geometry similar to mtb's? I don't mean 63deg head angles and 1350mm wheelbases, but just a bit more stable geo. It just seems that road bikes seem to priorities "quick" handling (even endurance or tourers or whatever seem to be only very marginally different). Steeper seat angles which mean longer reaches with shorter stems and slacker head angles etc.
To my uneducated mind, surely if the speeds are higher on the road than mtb (which they are), and even the twistiest of roads is still wideopen compared to a tight singletrack trail, wouldn't longer road bikes make it easier for riders to spend less "energy" on controlling the bike? I know that a bigger bike is heavier, but other than that is there any reason why road bikes haven't got any "stable" geometry wise over the years?
